HT230 Dedicated GPU Mini PC with RTX4060/RTX5060, Intel Core i9/i7, Dual LAN, DDR4/DDR5, Multi-Display
Model name: HT230
Products Features
– Supports 4-channel display output for simultaneous display or synchronous different displays
– Built-in GTX 1660s 6G/ RTX 3070M 8G / RTX 3060M 12G/RTX2060 6GB/ RTX4060 8G/RTX5060 8G.
– 2 x DDR4 SO-DIMM(11th gen)/DDR5(13th gen) RAM, MAX 64GB.
– Support 2 x M.2 2280 SATA / NVME SSD, 1 x 2.5 inch SATA SSD/HDD
– Support 6*USB3.0+2*USB2.0+2 RJ45 LAN
– Support PXE, Auto Power On, RTC, Wake On LAN.
– Three silent copper fans as a heat sink for 7×24 hours stable performance.
Product Details
Specification
Ordering information
Product Details
The HT230 Dedicated GPU Mini PC is a compact high-performance computer designed for graphics-intensive workloads, AI applications, visual inspection, video editing, gaming, and professional workstations. It supports Intel Core i9-11900KB or Intel Core i7-13620H processors with optional GTX1660, RTX2060/RTX3060M, RTX4060, or RTX5060 dedicated GPU, delivering strong computing and graphics performance in a space-saving desktop design.
With dual LAN, WiFi, Bluetooth, expandable DDR4/DDR5 memory, dual M.2 SSD storage, and multiple display outputs, HT230 is ideal for users who need powerful GPU acceleration in a compact mini PC form factor.
Product Features
Powerful CPU Options: Intel Core i9-11900KB or Intel Core i7-13620H
Dedicated GPU Support: RTX1660 6GB, RTX3060M 12GB, RTX4060 8GB, RTX5060 8GB
High-Speed Memory: DDR4 for i9-11900KB, DDR5 for i7-13620H, up to 64GB
Flexible Storage: 2 × M.2 2280 SATA/NVMe SSD + 1 × 2.5-inch SATA SSD/HDD
Multi-Display Output: HDMI2.0 and DP1.4 outputs for 4K/8K display setups
Dual Gigabit LAN: 2 × Realtek RJ45 LAN, 100/1000M
Wireless Connectivity: Dual-band WiFi 802.11ac, Bluetooth 4.0/4.2, dual antennas
Rich I/O Ports: USB 3.0, Type-C, HDMI/DP, LAN, MIC, SPK, DC IN
Efficient Cooling Design: Smart silent fan cooling with motherboard fan and GPU fans
Compact Aluminum Body: 300 × 236 × 63mm, desktop placement, black aluminum alloy chassis
OS Support: Windows 10/11, Linux Ubuntu
Display Output Note
RTX4060 / RTX5060 Only: 1 × HDMI2.0 4K@60Hz + 3 × DP1.4 8K@60Hz
RTX1660 / RTX3060M Only: 2 × DP1.4 8K@60Hz + 2 × HDMI2.0 4K@60Hz
Product Application Industries
AI large model local deployment
Machine vision and visual inspection
Video editing and content creation
3D rendering and graphics workstation
Gaming and entertainment
Edge AI computing
Digital signage and multi-screen display
Industrial image processing
Smart factory and automation
Office workstation and business computing
Specification
| Motherboard | |
| CPU | Intel Core i9-11950H(24M Cache, 8cores, 16 threads up to 5.0 GHz) |
| Intel Core i5-13600H (18M Cache, 12cores, 16threads max up to 4.8 GHz) | |
| Intel Core i7-13620H (24M Cache, 10cores, 12threads max up to 4.9 GHz) | |
| Intel Core i7-13700H (24M Cache, 14cores, 20threads max up to 5.2 GHz) | |
| GPU | Nvidia GeForce RTX 3060M 12G / RTX 3070M 8G |
| GeForce GTX1660 6G GDDR6 | |
| RTX4060 8GB / RTX5060 8G | |
| Network Card | 2 x Realtek LAN, 100/1000M |
| WiFi and Bluetooth | With dual antennas, 802.11ac 2.4+5Ghz, bt 4.0/4.2 |
| Memory | i5-13600H/ i7-13620H / i7-13700H: 2 x SO-DIMM DDR5 slots, 4800/5600MHz i9-11950H: 2 x SO-DIMM DDR4 slots, 2133/2400/2666/3200MHz |
| Storage | 2 x M.2 2280 SATA / NVME (PCIE3.0+PCIE4.0)SSD 1 x 2.5 inch SATA SSD/HDD |
| Expand | 1 x M.2 PCIE WiFi module |
| I/O Interfaces | |
| Front Panel | 1 x Power button |
| 1 x Type-C(4K@60Hz) | |
| 4 x USB 3.0 | |
| Rear Panel | 1 x DC_in |
| 2 x USB 3.0 | |
| 2 x RJ45 LAN | |
| 1 x MIC, 1 x SPK | |
| Display port | 1 x HDMI2.0+1 x DP1.4+1 x DVI for GTX1660 Only |
| 2 x DP1.4(8K@60Hz)+2 x HDMI2.0(4K@60Hz) for RTX3060M/RTX3070M Only | |
| 1 x HDMI2.0(4K@60Hz)+ 2 x DP1.4(8K@60Hz) for RTX4060 / RTX 5060 Only | |
| Software Support | |
| System Support | Windows 10/11, linux ubuntu etc |
| General | |
| Cooling Mode | Smart silent fan, sound below 25 decibels (place it vertically to reduce the fan speed & sound effectively) |
| Power Supply | DC100-240V AC/50-60Hz, 19V/15.79A |
| Heat-sink | 3 x turbo Fan |
| Packing List | HT230 Mini pc, power supply, power cord, vertical stand, warranty card |
| Mechanical | |
| Material | Aluminum alloy |
| Colour | Black |
| Size | 320mm(L)x240mm(W)x57mm(H) |
| Weight | 5Kgs |
| Insallation Method | Desktop type |
| Operating Temperature | 0°C~50°C Centigrade |
| Storage Temperature | ‘-20°C~80°C Centigrade |
| Relative Humidity | 10%~90% (non-condensing) |
Ordering information
| Model | Processor | Graphics | Frequency | Display | Memory | Storage | LAN | USB | Power |
| HT230 | I7 10870H | Nvidia GeForce RTX 3070M 8G | 2.2~5.0 GHz | 2*HDMI/2*DP | 2 x SO-DIMM DDR4 | 2 x M.2 2280 SATA SSD/ 1 x 2.5-inch SATA SSD/HDD | 2 | 8 | 19V/15.79A |
| Nvidia GeForce RTX 3060M 12G | |||||||||
| GeForce GTX1660S 6G GDDR6 | |||||||||
| RTX4060 8GB / RTX5060 8GB | 1*HDMI/3*DP | ||||||||
| HT230 | I9 10980HK | Nvidia GeForce RTX 3070M 8G | 2.4~5.3 GHz | 2*HDMI/2*DP | 2 x SO-DIMM DDR4 | 2 x M.2 2280 SATA SSD/ 1 x 2.5-inch SATA SSD/HDD | 2 | 8 | 19V/15.79A |
| Nvidia GeForce RTX 3060M 12G | |||||||||
| GeForce GTX1660S 6G GDDR6 | |||||||||
| RTX4060 8GB / RTX5060 8GB | 1*HDMI/3*DP | ||||||||
| HT230 | i9-11950H | Nvidia GeForce RTX 3070M 8G | max up tp 5GHz | 2*HDMI/2*DP | 2 x SO-DIMM DDR5 | 2 x M.2 2280 SATA SSD/ 1 x 2.5-inch SATA SSD/HDD | 2 | 8 | 19V/15.79A |
| Nvidia GeForce RTX 3060M 12G | |||||||||
| GeForce GTX1660S 6G GDDR6 | |||||||||
| RTX4060 8GB / RTX5060 8GB | 1*HDMI/3*DP | ||||||||
| HT230 | i5-13600H | Nvidia GeForce RTX 3070M 8G | max up tp 4.8 GHz | 2*HDMI/2*DP | 2 x SO-DIMM DDR5 | 2 x M.2 2280 SATA SSD/ 1 x 2.5-inch SATA SSD/HDD | 2 | 8 | 19V/15.79A |
| Nvidia GeForce RTX 3060M 12G | |||||||||
| GeForce GTX1660S 6G GDDR6 | |||||||||
| RTX4060 8GB / RTX5060 8GB | 1*HDMI/3*DP | ||||||||
| HT230 | i7-13620H | Nvidia GeForce RTX 3070M 8G | max up tp 4.9 GHz | 2*HDMI/2*DP | 2 x SO-DIMM DDR5 | 2 x M.2 2280 SATA SSD/ 1 x 2.5-inch SATA SSD/HDD | 2 | 8 | 19V/15.79A |
| Nvidia GeForce RTX 3060M 12G | |||||||||
| GeForce GTX1660S 6G GDDR6 | |||||||||
| RTX4060 8GB / RTX5060 8GB | 1*HDMI/3*DP | ||||||||
| HT230 | i7-13700H | Nvidia GeForce RTX 3070M 8G | max up tp 5.2 GHz | 2*HDMI/2*DP | 2 x SO-DIMM DDR5 | 2 x M.2 2280 SATA SSD/ 1 x 2.5-inch SATA SSD/HDD | 2 | 8 | 19V/15.79A |
| Nvidia GeForce RTX 3060M 12G | |||||||||
| GeForce GTX1660S 6G GDDR6 | |||||||||
| RTX4060 8GB / RTX5060 8GB | 1*HDMI/3*DP |
Please note that the CPU will be updated according to the release time of Intel/AMD.
If the latest CPU is not shown here, please contact our sales team to get the latest information!
