Micro Firewall Appliance 2.5gbe Celeron N5105 6×2.5GbE I225 LAN Firewall Network Appliance
– 6*Intel i225/i226 2.5G RJ45 Ethernet Controllers, 2*USB3.0.
– 2*DDR4 SO-DIMM 2933 MHz RAM slots, Maximum support 32GB.
– 1*mSATA+1*2.5inch SATA SSD/HDD
– Support 1 x VGA, 1HDMI optional
– 2*Mini PCIE Extension slots, support WiFi and 4G/5G module at the same time.
– Support AES-NI, ESXI, Watchdog, Auto power on, RTC, PXE boot, Wake-on-LAN
– Widely Applications: Data centers, enterprise networks, Network Virtualization and Cloud Environments,Home Networks
Product Details
Specification
Ordering information
Product Details
JIRUICC 1U Firewall Router 6 LAN 2.5G LAN with Celeron N5105,Supported AES-NI, ESXI, Watchdog, Auto power on, RTC, PXE boot, Wake-on-LAN
This Rackmount 1U Firewall Router with 6*Intel i225/I226 network card support 2.5GbE which can bring you faster network usage.
It is designed to fit into standard server racks and cabinets, making it an ideal choice for data centers, server rooms, and other environments where space is limited.
It typically includes features like: Firewall Protection, Routing and Network Segmentation, Multiple WAN Connections, Traffic Management and Quality of Service, Monitoring and Reporting
This Firewall Router is fanless and slient router pc and preinstall with pfSense, also it support OPNsense/OpenWrt/Unbutun/windows and other popular open-source software solutions.
It is Widely used in: Home networks / Data centers / enterprise networks / Public netowrks / internet service providers
Specification
| Material | Iron |
| Colour | Silver(any color can be customized for bulk order) |
| Size | 210 x200 x 45(mm) |
| Weight | 3Kgs |
| Insallation Method | Desktop type |
| Motherboard | |
| Intel Celeron N5105, Quad-core and four-thread, main frequency: 2.0GHz up to 2.9Ghz(optional N5100) | |
| Network Card | Intel 6*I225 1G adaptive network card interface |
| Graphic | Intel HD Graphics |
| RAM | 2 x DDR4 2933 MHz SODIMM memory slots, up to 32GB |
| Storage | 1 x mSATA SSD, 1 x 2.5 inch SSD/HDD |
| Display | 1 x VGA, 1 x HDMI(Optional) |
| Expand | Support 1 MINI PCIE channel (can be WIFI/Bluetooth/4G) |
| Others | Support Power-on boot, scheduled boot, wake-up on LAN, PXE boot, watchdog |
| I/O Interfaces | |
| Front Panel | 1 x VGA |
| 1 x DC | |
| Rear Panel | 1 x Console |
| 2 x USB2.0/3.0 | |
| 6 x LAN | |
| Software Support | |
| System Support | Windows,10,Server2012/EXSI/Ikuai/Mikrotik/Openwrt/Ubuntu/Centos/Pfsense/Linux |
| BIOS | AMI EFI BIOS |
| General | |
| Cooling Mode | With Fan |
| Power Supply | DC12V-4A 5.5*2.5 |
| Packing List | FT6L-N5105 firewall, power cord, warranty card |
Ordering information
| Model | Processor | Graphics | Frequency | Display | Memory | Storage | LAN | USB | Power |
| FT6L-N5105 | N5105 | Intel UHD Graphics | 2.0~2.9 GHz | VGA | 2 x SO-DIMM DDR4, Max 32G | 1 x Msata+1 x 2.5inch SSD/HDD | 6 x i225/226 | 2 | 12V/4A |
