Gaming PC with intel 8-9th Gen Intel I5 I7 Xeon
1*HDMI+1*DP+1DVI+1LAN+4*USB 3.0+3*USB2.0+SPK+MIC+19V DC IN
Products Features
-Intel 8-9th Gen Intel Core i5/i7/Xeon Processor
-Dual SODIMMs for up to 64GB DDR4 Memory
-Support M.2 2280 SATA/NVME SSD, 2.5 Inch SSD/HDD
-Aluminum chassis, 280 x 200 x 65mm
-Embedded Expansion: M.2 PCIe for WiFi
-Rich I/O: DVI, DP, HDMI, DC, LAN, 2 x USB 3.0, 5 x USB 2.0, Spk, Mic
-Support Restore AC Power Loss/diskless boot
-Support 3-channel display out(DP, HDM and DVI) for simultaneous display or synchronous different display up to 8K output, 4K DP1.4, HDMI2.0
Product Details
Specification
Ordering information
Product Details
HT210 is a Fan cooling Gaming mini PC with intel 8-9th Gen Intel I5 I7 Xeon processor. Support 3-channel display out(DP, HDM and DVI) for simultaneous
Redefine the new form of computer, Compact, Space-saving, Fanless design, less noise disturbance, Low power consumption and Energy saving, easy to carry, stable performance
Widely Application Area: Cybercafe/Office working / Digital signage / Education/Call center /Conference room/Home entertainment /Home theater/Cloud Computing etc…
Specification
| Basic Information: | |
| CPU | Intel Core i3-9100F 3.6GHz up to 4.2GHz(Turbo boost Technology) 4 Cores 4 Threads 6MB Smart Cache TDP 65W |
| Intel Core i5-9400F 2.9GHz up to 4.1GHz(Turbo boost Technology) 6 Cores 6 Threads 9MB Smart Cache TDP 65W | |
| Intel Core i7-9750H, 6 Core 12 Threads, 2.6GHz, turbo 4.5GHz, 12MB Intel® Smart Cache,Intel® UHD Graphics 630 | |
| Intel Core i7-9700F 3.0GHz up to 4.7GHz(Turbo boost Technology) 8 Cores 8 Threads 12MB Smart Cache TDP 65W | |
| Intel® Xeon® Processor D-1581 24M Cache, 1.80 GHz (16 cores 32 threads) | |
| TDP | Refer to CPU |
| CPU interface | FCLGA1151 desktop CPU |
| BIOS | AMI BIOS, ACPI supported |
| Chipset | Intel CPU SOC |
| Memory | 2 x SO-DIMM DDR4 slot, up to 64GB |
| Dual Channel, DDR4-2400/DDR4-2666 | |
| OS | Windows 8/Windows 10/Linux |
| PXE | YES |
| Audio | ALC662 audio chip, 6-channel |
| Network | Onboard RTL 8111DL 10/100/1000 BaseT LAN |
| Video | NVIDIA GTX 1650 4GB DDR5 graphics and refer to CPU about integrated graphics |
| Input/output port | |
| Switch | 1 x Power On/Off Switch |
| Power | 1 x 19V DC In |
| LED | 1 x LED |
| USB | 5 x USB2.0, 2 x USB3.0 |
| Display | 1 x DP, 1 x HDMI, 1 x DVI, can switch VGA connector |
| LAN | 1 x RJ45 Giga LAN |
| Audio | 1 x MIC, 1 x SPK |
| Storage | |
| M.2 | 1 x M.2 slot for SSD, support NVME SSD |
| SATA | 1 x SATA3.0 slot for SATA HDD or SSD, support 6Gb/s |
| Wi-Fi | |
| Module | 1 x M.2 PCIE slot for Wi-Fi module |
| Antenna | 2 x inner RF cables and 2 x external antennas |
| Power and Working Environment | |
| Input | DC100-240V AC/50-60Hz |
| Output | DC 19V, recommend 19V/9.5A |
| Operating Temperature | 0/+70 Centigrade |
| Storage Temperature | -20/+80 Centigrade (-68~176°F) |
| Storage Temperature | ‘+70 Centigrade |
| Relative Humidity | 10%~90% (non-condensing) |
| Product Dimension & Details | |
| Size | 280x200x65mm |
| Weight | Net 2kg, Gross 2.5kg |
| Shell | Silver color aluminum alloy |
| Cooling Mode | Cooling Fan |
| Functions | Auto power on |
| Package Content | |
| Standard | 1xMini PC, 1xPower Adapter, 1xPower Cord, 1xScrews Bag,Wi-Fi antennas |
Ordering information
| Model | Processor | Graphics | Frequency | Display | Memory | Storage | LAN | USB | Power |
| HT210 | I5 9400F | GeForce GTX 1650 4G | 2.9~4.1 GHz | DP/HDMI/DVI | 2 x SO-DIMM DDR4, up to 64GB | 1 x M.2 2280 SATA / NVME SSD, 1 x 2.5 inch SATA SSD/HDD | 1 | 7 | 19V/9.5A |
| HT210 | I7 9700F | GeForce GTX 1650 4G | 3.0~4.7 GHz | DP/HDMI/DVI | 2 x SO-DIMM DDR4, up to 64GB | 1 x M.2 2280 SATA / NVME SSD, 1 x 2.5 inch SATA SSD/HDD | 1 | 7 | 19V/9.5A |
| HT210 | I7 9750H | GeForce GTX 1650 4G | 2.6~4.5 GHz | DP/HDMI/DVI | 2 x SO-DIMM DDR4, up to 64GB | 1 x M.2 2280 SATA / NVME SSD, 1 x 2.5 inch SATA SSD/HDD | 1 | 7 | 19V/9.5A |
| HT210 | Xeon D-1581 | GeForce GTX 1650 4G | 1.8~2.4 GHz | DP/HDMI/DVI | 2 x SO-DIMM DDR4, up to 64GB | 1 x M.2 2280 SATA SSD, 1 x M.2 2280 NVME SSD, 1 x 2.5 inch SATA SSD/HDD | 1 | 6 | 19V/9.5A |
| HT210 | Xeon D-1581 | NVIDIA Quadro K620 2G | 1.8~2.4 GHz | DP/DVI | 2 x SO-DIMM DDR4, up to 64GB | 1 x M.2 2280 SATA SSD, 1 x M.2 2280 NVME SSD, 1 x 2.5 inch SATA SSD/HDD | 1 | 6 | 19V/9.5A |
