JIERUICC Mini Pocket PC I7-1185G7 2 x HDMI2.0 2 Type-c
Products Features
Dimension: Palm size 110*110*36MM NUC design, Small body Strong Performance
CPU: Intel Gen11 i7-1185G7 3GHz up to 4.8Ghz Quad Cores Eight Threads
GPU: Intel Iris Xe Graphics
Ram: 1xDDR4 SODIMM slot, 2133/2666/3200MHz max 64GB
SSD: Support 1*M.2 2280 NVMe/PCIE3.0x2 SSD
WiFi: 1 x M.2 2230 slot for Wi-Fi & Bluetooth module, Intel 7260AC WIFI5
RJ45: 1 x 100/1000M realtek chip
I/O: 2 x USB3.0 + 2*USB2.0 , 2 x HDMI 2.0(4096×2304@60Hz), 2 x Type-C, 1 x RJ45 LAN, 1 x Audio, 1 x switch, 1 x DC IN
OS: Windows 10/11/OPNsesne/Ubuntu etc
Power: 12V 5A
Product Details
Specification
Ordering information
Product Details
JIERUICC Tiny PC GT490 with Palm size 110*110*36MM only. small body with strong performance
rich I/O Ports like 1* NIC RJ45, 2 x USB3.0 +2 x USB2.0, 2x HDMI2.0(4096×2304@60Hz), 2*Type-c Four display for connecting with multiple devices
for Various industry uses Like Office working pc / Digital Signage/ Enterprise / SME / Conference room / Education computer lab / Cloud Computing/Smart Robot/Smart Transportation etc…
* NUC Design and Efficient: This tiny computer GT490 NUC Mini PC small body with strong performance operates with Efficient heat dissipation of cooper turbo fan
* Powerful Performance: Equipped with an Intel Processor Intel Core i7-1185G7 3GHz up to 4.8Ghz Quad Cores Eight Threads, it delivers powerful computing performance.
* Versatile Storage: 1* M.2 NVME SSD, you have flexible storage options.
* Extensive Connectivity: Featuring 1 x LAN ports, 2*HDMI, 2*type-c, and various USB ports, it offers extensive connectivity for various devices.
* Operating System Compatibility: Compatible with Windows 11 and Linux Ubuntu, making it suitable for various software applications.
-Support Watchdog, Auto power on, Wake-On-LAN, PXE
Specification
| Basic Information: | |||
| CPU | Onboard Intel Tiger Lake Gen11 i7-1185G7 3.0GHz up to 4.8Ghz Quad Cores Eight Threads | ||
| TDP | 12-28W | ||
| BOIS | AMI BIOS, ACPI supported | ||
| Chipset | Tiger Lake | ||
| Memory | 2* SO-DIMM DDR4 Slot Support 4GB/8GB/16GB/32GB DDR4 Max support 64GB | ||
| OS | Windows 10/11, Linux | ||
| Audio | Integrated High Definition Audio Controller ALC892 | ||
| Network | 2 x Realtek 10/100/1000 BaseT LAN | ||
| Video | Intel Iris Xe Graphics | ||
| Storage: | |||
| M.2 | 1 x M.2 PCIE3.0 slot Nvme SSD, , support 6Gb/s | ||
| Wi-Fi: | |||
| Module | 1 x M.2 2230 slot for Wi-Fi & Bluetooth module, Intel 7260AC WIFI5 | ||
| Antenna | 2 x inner RF cables and 2 x external antennas | ||
| Input/output port： | |||
| Switch | 1 x Power On/Off Switch | ||
| Power | 1 x 12V DC In | ||
| USB | 2 x USB3.0 + 2*USB2.0 | ||
| Display | 2 x HDMI 2.0(4096×2304@60Hz), 2 x Type-c | ||
| LAN | 1 x RJ45 Giga LAN | ||
| Audio | 1 x Audio | ||
| Power and Working Environment: | |||
| Input | 100-240V AC/50-60Hz | ||
| Output | 12V~+19V, recommend 12V/5A | ||
| Operating Temperature | -20°C/+60°C | ||
| Storage Temperature | -30°C/+80°C | ||
| Relative Humidity | 10%~90% @30°C(non-condensing) | ||
| Product Dimension & Details: | |||
| Functions | Watchdog, Auto power on, Wake-On-LAN, PXE | ||
| Size | 110*110*36MM | ||
| Weight | Net 0.65kg, Gross 1.2kg | ||
| Shell | Magnesium alloy Grey color shell | ||
| Cooling Mode | FAN | ||
| Package Content： | |||
| Standard | 1xMini PC, 1xPower Adapter, 1xPower Cord, 1xScrews Bag | ||
Ordering information
| Model | Processor | Graphics | Frequency | Display | Memory | Storage | LAN | USB | Power |
| GT490 | i7 1185G7 | Intel Iris Xe Graphics | 3GHz up to 4.8Ghz | TYPE-C/DP/HDMI/ | 2 x SO-DIMM DDR4, up to 64GB Max | 1 x M.2 2280 PCIE 3.0, SSD | 1 | 2*USB3.0 2*USB2.0 | 12V/5A PD 65W |
