1U Network Firewall Appliance Xeon E3-1225 / I3/ I5/ I7, 8 x LAN, 2 USB3.0
– I/O Ports: 8x Intel I211AT(8*i226V (Optional))+1*VGA+1*RJ45 Console+1 x HDMI(Optional)+2 x 3.0+2 x optical ports
– 2*DDR4 SO-DIMM 2133/2400 MHz RAM slots, Maximum support 32GB.
– 1*mSATA+1*2.5inch SSD/HDD. max up to 4TB
– Support 1 x VGA, 1*HDMI Optional
– 2*Mini PCIE Extension slots, support WiFi /BT and 4G/5G module at the same time.
– Support AES-NI, ESXI, Watchdog, Auto power on, RTC, PXE boot, Wake-on-LAN
– Widely Applications: Telecommunication rooms, Data centers, Enterprise networks, cloud service providers, internet service providers
Product Details
Specification
Ordering information
Product Details
The JIERUICC GT8L-01 Firewall Appliance is a high-performance solution crafted for adaptable network security needs.
Boasting compatibility with LGA1151 Core i3/i5/i7 Xeon processors, eight Intel I211AT Ethernet ports (with the option to upgrade to 2.5G i226V),
and featuring two Mini PCIe slots for extensive functionality,
it ensures both powerful performance and remarkable versatility within a compact design.
Accommodates a diverse selection of robust processors, ranging from Core i3/i5/i7 to Xeon series, catering to various performance requirements.
Features 8 x Intel I211AT Ethernet ports, delivering outstanding networking capabilities, with the possibility of upgrading to the faster i226V for improved speeds.
Exploit the dual Mini PCIe slots for flexible expansion opportunities, whether it involves integrating Wi-Fi, Bluetooth, or 4G connectivity.
Supports up to 32GB DDR4 memory across two slots, alongside a flexible storage configuration with M-SATA and four SATA slots for HDD/SSD.
Seamlessly connect to displays with VGA and HDMI outputs, facilitating efficient display configurations compatible with diverse monitors or screens.
The power supply unit offers a versatile input range (110-240V) and comes in 200W or 300W options, ensuring stable performance.
Specification
| Material | Iron, Aluminum panel |
| Colour | Gray |
| Size | 440 x 257 x 45(mm) (Excluding hanging ears) |
| Weight | 7.5Kgs |
| Insallation Method | Rack Mounting/Wall Mounting/Desktop Mounting |
Motherboard
CPU | Intel Core i3-9100 4 Cores 4 Threads CPU 3.6Ghz up to 4.2Ghz,6 MB Intel® Smart Cache,Intel® UHD Graphics 630 Intel Core i5-9400 6 Cores 6 Threads CPU 2.9Ghz up to 4.1Ghz,9 MB Intel® Smart Cache,Intel® UHD Graphics 630 Intel Core i7-9700 8 Cores 8 Threads CPU 3.0Ghz up to 4.7Ghz,12 MB Intel® Smart Cache,Intel® UHD Graphics 630 Intel Xeon E3-1225 V5 4 Cores 4Threads CPU 3.1Ghz up to 3.4Ghz,6 MB Intel® Smart Cache |
Network Card | 8*i211AT (Default) 8*i226V (Optional) It can be expanded to include either 2/4 10 Gigabit ports or 4 Gigabit optical ports. |
| Graphic | Integrated UHD Graphics (Depends on the cpu) |
| Memory | 2 x DDR4 2133/2400MHz SO-DIMM (max Up to 32GB) |
Storage | 1 x M-SATA; 4 x SATA (1*2.5″/ 3.5″HDD/SSD Bracket) |
| Display | 1 x VGA, 1 x HDMI (Optional) |
Expand | 1 x Mini PCIe for WiFi/Bluetooth module 1 x Mini PCIe for 4G module 1 x PCIe x8 Channel Expansion slot |
| Others | Support Power-on boot, scheduled boot, wake-up on LAN, PXE boot, watchdog |
I/O Interfaces
| Front Panel | 1 x VGA |
| 3 x WiFi Holes | |
| 1 x HDMI(Optional) | |
| 2 x Cooling fan | |
| 1 x Switch | |
| 1 x AC socket | |
| Rear Panel | 1 x Console |
| 2 x 3.0 | |
| 2 x optical ports (expandable to 4/2 Gigabit or 10 Gigabit optical ports) | |
| 8 x LAN |
Software Support
| System Support | Windows,10,Server2012/EXSI/Ikuai/Mikrotik/Openwrt/Ubuntu/Centos/Pfsense/Linux |
| BIOS | AMI EFI BIOS |
General
| Cooling Mode | With Fan, good heat dissipation |
Power Supply | Industrial grade power supply Taiwan Mean Well LRS-50-12 Input: 100-240V~1.0A Output: 12V4.2A |
| Packing List | JIERUICC GT8L-01 firewall PC, power cord, warranty card |
Environment
| Operating temperature | -0~+50°C (commercial HDD), -20°C~+50°C (industrial SSD), surface air flow |
| ambient temperature | 5~90°C relative humidity, non-condensing |
| Certification | CE, FCC, CCC, ROHS |
Ordering information
| Model | Processor | Graphics | Frequency | Display | Memory | Storage | LAN | USB | SFP | Power |
| GT8L-01 | I3 9100 | Intel UHD Graphics 630 | 3.60 up to 4.20GHz | 1 x VGA | 2 x SO-DIMM DDR4 | 1 x mSATA/1 x 2.5 Inch SATA | 8 | 2 | 2 / 4 | DC_IN 12V |
| GT8L-01 | I5 9400 | Intel UHD Graphics 630 | 3.60 up to 4.20GHz | 1 x VGA | 2 x SO-DIMM DDR4 | 1 x mSATA/1 x 2.5 Inch SATA | 8 | 2 | 2 / 4 | DC_IN 12V |
| GT8L-01 | I7 9700 | Intel UHD Graphics 630 | 3.60 up to 4.20GHz | 1 x VGA | 2 x SO-DIMM DDR4 | 1 x mSATA/1 x 2.5 Inch SATA | 8 | 2 | 2 / 4 | DC_IN 12V |
| GT8L-01 | E3-1225 V5 | Intel HD Graphics P530 | 3.60 up to 4.20GHz | 1 x VGA | 2 x SO-DIMM DDR4 | 1 x mSATA/1 x 2.5 Inch SATA | 8 | 2 | 2 / 4 | DC_IN 12V |
