Mini Desktop PC Intel 12th Gen i9-12900H
Products Features
– 2 x SODIMM DDR4 memory slots up to 64GB more powerful performance
improves work efficiency and gives you a smooth experience.
– Support 2*HDMI, DP, and Type-C four display output synchronously.
– With a silent copper cooling fan, works as long as 24 hours.
– Optional built-in Wi-Fi and Bluetooth with internal antennas make the signal more
stable and stronger.
– Support PXE, Auto Power On, RTC, Wake On LAN
Product Details
Specification
Ordering information
Product Details
JIERUICC Mini desktop pc GT980 supports multiple intel 12th generation processors like i5-1240P / i7-1260P / i7-1270P / i7-1270P / i7-12700H / i9-12900H
with rich I/O Ports like Dual NIC RJ45 2.5Gbps, 8USB Ports,2 x HDMI 1.4, 1 x DP 1.2, Type-C, and Triple display for connecting with multiple devices for Various industry uses Like
AI Computing / Digital Signage/ Enterprise / Video editing / Conference room / Education computer lab / Cloud Computing/Smart Robot/Smart Transportation etc…
* Fan cooling design: This Mini PC operates with a fan, Let it maintain good heat dissipation while running multiple tasks.
* Powerful Performance: Equipped with an Intel 12th generation i9 Processor and support for up to 64GB DDR4 RAM, it delivers powerful computing performance.
* Versatile Storage: With slots for mSATA SSD, M.2 NVME SSD, and 2.5-inch SATA SSD/HDD, you have flexible storage options.
* Extensive Connectivity: Featuring 2 x LAN ports, 2 x HDMI, DP, and various USB ports, it offers extensive connectivity for various devices.
* Operating System Compatibility: Compatible with Windows 11 and Linux Ubuntu, making it suitable for various software applications.
-Support Watchdog, Auto power on, Wake-On-LAN, PXE
Specification
| Basic Information: | ||||
| CPU | Intel Alder Lake 12th Gen Core i5-1240P 12 cores 16 threads 4.40 GHz 28 W TDP 12 MB Intel® Smart Cache Intel® Iris® Xe Graphics eligible | |||
| Intel Alder Lake 12th Gen Core i7-1260P 12 cores 16 threads 4.70 GHz 28 W TDP 18 MB Intel® Smart Cache Intel® Iris® Xe Graphics eligible | ||||
| Intel Alder Lake 12th Gen Core i7-1270P 12 Cores 16 threads 4.80 GHz 28W TDP 18 MB Intel® Smart Cache Intel® Iris® Xe Graphics eligible | ||||
| Intel Alder Lake 12th Gen Intel® Core™ i7-1280P 14 cores 20 threads 4.80 GHz 24 MB Intel® Smart Cache 28W TDP Intel® Iris® Xe Graphics eligible | ||||
| Intel Alder Lake 12th Gen Intel® Core™ i7-12700H 14 cores 20 threads 4.70GHz 24 MB Intel® Smart Cache 45W TDP Intel® Iris® Xe Graphics eligible | ||||
| Intel Alder Lake 12th Gen Intel® Core™ i9-12900H 14 cores 20 threads 4.80GHZ 24 MB Intel® Smart Cache 45W TDP Intel® Iris® Xe Graphics eligible | ||||
| TDP | 28W/45W | |||
| Motherboard Size | 120mm×150mm | |||
| Chipset | Alder Lake | |||
| Memory | 2 x SO-DIMM DDR4 Slot , Support 4GB/8GB/16GB/32GB/64GB DDR4 2133MHz/2400MHz/2666MHz/3200MHZ | |||
| OS | Windows10/11/Linux | |||
| Network | Onboard Intel i225/226 2.5G Network Connectio | |||
| Video | Refer to the above CPU | |||
| Wi-Fi: | ||||
| Module | 1×M.2 NGFF 2230 slot for Wifi (802.11 b/g/n/AC/AX )module and Bluetooth (4.0 or above)module | |||
| Power and Working Environment: | ||||
| Input | DC100-240V AC/50-60Hz | |||
| Output | DC +12V~+19V, recommend 19V 4.74A | |||
| Operating Temperature | -10/+50 Centigrade | |||
| Storage Temperature | -20/+85 Centigrade | |||
| Relative Humidity | 5%~95% @30°C(non-condensing) | |||
| Input/output port： | ||||
| Switch | 1 x Power On/Off Switch | |||
| Power | 1×DC （55*25) 12-19V 65W/90W | |||
| USB | 2×USB2.0 4×USB3.0 | |||
| Display | 2×HDMI Out 2.0 4K 60HZ 1×DP 1.4(support Thunderbolt 4) | |||
| LAN | 2×RJ45 2500M | |||
| Type-c | 1 x Type-C | |||
| Audio | 1 x MIC, 1 x SPK | |||
| Storage: | ||||
| SATA | 1 x SATA3.0 slot for SATA HDD or SSD, support 6Gb/s | |||
| M.2 | 1×M.2 2280 slot for NVME PCIE x 4 / SATA3.0 SSD 1×M.2 2280 slot for NVME PCIE x 4 GEN4 | |||
| Product Dimension & Details: | ||||
| Size | 45.5*174.5*128.5mm | |||
| Weight | NW：0.49KG GW：1.6KG | |||
| Shell | Plastic | |||
| Cooling Mode | All-copper turbo fan | |||
| Functions | PXE, Auto Power On, RTC, Wake On LAN | |||
| Package Content： | ||||
| Standard | 1xMini PC, 1xPower Adapter, 1xPower Cord, 1xScrews Bag | |||
Ordering information
| Model | Processor | Graphics | Frequency | TDP | Display | Memory | Storage | LAN | USB | Power |
| GT980 | i5-1240P | Intel® Iris® Xe Graphics eligible | 3.3GHz up to 4.4GHz | 28W | 1DP1.4+2HDMI 2.0 | 2 x SO-DIMM DDR4, up to 64GB | 2 x M.2 2280 (SATA/NVME) 1 x SATA3.0 | 2 | 4*USB3.0 2*USB2.0 | 19V/4.7A |
| GT980 | i7-1260P | Intel® Iris® Xe Graphics eligible | 3.4GHz up to 4.7GHz | 28W | 1DP1.4+2HDMI 2.0 | 2 x SO-DIMM DDR4, up to 64GB | 2 x M.2 2280 (SATA/NVME) 1 x SATA3.0 | 2 | 4*USB3.0 2*USB2.0 | 19V/4.7A |
| GT980 | i7-1270P | Intel® Iris® Xe Graphics eligible | 3.5GHz up to 4.8GHz | 28W | 1DP1.4+2HDMI 2.0 | 2 x SO-DIMM DDR4, up to 64GB | 2 x M.2 2280 (SATA/NVME) 1 x SATA3.0 | 2 | 4*USB3.0 2*USB2.0 | 19V/4.7A |
| GT980 | i7-1280P | Intel® Iris® Xe Graphics eligible | 3.6GHz up to 4.8GHz | 28W | 1DP1.4+2HDMI 2.0 | 2 x SO-DIMM DDR4, up to 64GB | 2 x M.2 2280 (SATA/NVME) 1 x SATA3.0 | 2 | 4*USB3.0 2*USB2.0 | 19V/4.7A |
| GT980 | i7-12700H | Intel® Iris® Xe Graphics eligible | 3.5GHz up to 4.7GHz | 45W | 1DP1.4+2HDMI 2.0 | 2 x SO-DIMM DDR4, up to 64GB | 2 x M.2 2280 (SATA/NVME) 1 x SATA3.0 | 2 | 4*USB3.0 2*USB2.0 | 19V/4.7A |
| GT980 | i9-12900H | Intel® Iris® Xe Graphics eligible | 3.8GHz up to 5.0GHz | 45W | 1DP1.4+2HDMI 2.0 | 2 x SO-DIMM DDR4, up to 64GB | 2 x M.2 2280 (SATA/NVME) 1 x SATA3.0 | 2 | 4*USB3.0 2*USB2.0 | 19V/4.7A |
