Industrial PC GT1000 with External SIM Card Slot Support 4G Module
1*SIM Card slot+2*RS232 COM+1*HDMI+1*VGA+2*RJ45 Gigabit LAN+4*USB2.0+2*USB3.0+SPK+MIC+12V DC IN
Products Features
– Brushed Full Aluminum Alloy Black color shell, Exquisite Appearance Design.
– Fanless system without cooling fan, Zero noise,Stable Performance, work as long as 24 hours.
– Built-in Wi-Fi / Bluetooth with dual external antennas.
– 2x SO-DIMM DDR3L Slot Support 2GB/4GB/8GB DDR3/L/-RS 1333/1600
– Can install M-sata SSD+2.5” SATA HDD together.
– 2*RS232 COM Port+1 x HDMI+1x VGA+2 x RJ45 Giga LAN+4 x USB2.0,2 x USB3.0+SPK+MIC+12V DC IN
– Can be mounted on the wall by long screws.
-Support Restore AC Power loss/LAN PXE boot/ WOL on windows 7
Product Details
Specification
Ordering information
Product Details
Inustrial Computer GT1000 with External SIM Card slot support SIM Card for 4G Module to get network for some products with hard working environments don’t support wifi network. it with rich I/O Ports like RS232 RS485 Dual LAN RJ45 6USB Ports for connecting with multiple device for Various industry uses
Like Industrial Automation / AI / IOT Internet of Things/Smart Education /Smart Medical/Smart City /Digital Signage/Cloud Computing/Smart Robot/Smart Transportation/New Retail(Kiosk)/Network Security etc…
Specification
| General | |
| CPU | Onboard Intel Pentium N3520 2.166GHz up to 2.42Ghz Quad Core Four Threads (Support Turbo boost Technology) Onboard Intel Celeron N2920 1.86GHz up to 2.0Ghz Quad Core Four Threads (Support Turbo boost Technology) |
| Core (FSB) | 100MHz |
| CPU Technique | 22nm |
| L3 Cache | 2 MB, CPU integrated |
| Motherboard | Intel CRESCENTBAY ( Lynx Point-LP ) |
| Support GPIO | |
| BOIS | AMI BIOS, ACPI supported |
| Support Auto power on | |
| Chipset | Intel BTY SOC |
| Memory | 1* SO-DIMM DDR3L Slot |
| Support 4GB/8GB DDR3L 1333 (Optional) | |
| Storage | 1*MSATA SSD: 16G/32G/64G/128G/256G/512G/1TB((Optional)) |
| 1*SATA HDD: 320G/500G/1TB(Optional) | |
| Operating System | Windows 7/Windows 8/Windows 10/Linux |
| Audio | ALC662 HD Audio, 6 channel sound |
| Network | Onboard Intel i211 Gigabit Network Connection |
| 10/100Mbps/1000Mbps BaseT LAN | |
| Video | Intel Haswell- ULT Integrated Graphics Controller |
| Intel HD Graphics | |
| I/O port | |
| front panel ports | 1* Switch On/Off, 1*LED, 2*USB3.0, 4*usb2.0, 2*RS232/422/485 COM |
| Backside ports | 1*MIC, 1*SPK, 2*RJ45 LAN, 1*HDMI, 1*VGA, 1*DC IN, 2*Wi-Fi |
| COM | 2* RS232/RS422/RS485(convert from BIOS) |
| Internal ports | 1*M-SATA3.0 port, support 6Gb/s |
| 1*SATA3.0 port, support 6Gb/s | |
| 1*mini PCIE-half port for WiFi module | |
| 1*mini PCIE-full port for 4G module | |
| SIM slot | Micro SIM, with PUSH function(on the side) |
| Power and Working Environment | |
| Input | DC100-240V AC/50-60Hz |
| Output | DC 12V/5A |
| Operating Temperature | -10/+60 Centigrade(22°F~130°F) |
| Storage Temperature | -20/+80 Centigrade (-68°F~176°F) |
| Relative Humidity | 10%~90% (non-condensing) |
| Product Dimension & Details | |
| Size | 175*125*37mm |
| Net Weight | 0.85KG |
| Gross Weight | 1.5KG(incl. package accessories) |
| Consumption | 10W |
| Shell | Black color aluminum alloy |
| Package Accessories | Mini PC.Power adapter, dual Wi-Fi antennas(optional),a Screw Bag |
Ordering information
Model |
Processor |
Graphics |
Frequency |
TDP |
Display |
Memory |
Storage |
LAN |
USB |
Power |
| GT1000-J1900 | Celeron J1900 | Intel® HD Graphics | 2.0~2.42 GHz | 10 W | VGA/HDMI | 1 x SO-DIMM DDR3L | 1 x 2.5 inch/1 x M-SATA | 2 | 6 | 12V/3A |
| GT1000-N2920 | Celeron N2920 | Intel® HD Graphics | 1.86~2.0 GHz | 7.5 W | VGA/HDMI | 1 x SO-DIMM DDR3L | 1 x 2.5 inch/1 x M-SATA | 2 | 6 | 12V/3A |
| GT1000-N3520 | Pentium N3520 | Intel® HD Graphics | 2.17~2.42 GHz | 7.5 W | VGA/HDMI | 1 x SO-DIMM DDR3L | 1 x 2.5 inch/1 x M-SATA | 2 | 6 | 12V/3A |
