AMD Ryzen Mini PC 5500U 5900HX 6900HX S500+
3 Display: HDMI2.0+DP1.4 and Type-C for 3x4K@60Hz+2xRJ45 LAN+Dual band AC(AX201)WiFi/Bluetooth
– Onboard AMD Radeon™ VEGA Graphics with fast graphics processing capabilities for gaming and 3D design.
– 2xSODIMM DDR4 ram slot up to 64GB
– Support HDMI2.0+DP1.4 and Type-C for 3x4K@60Hz video display synchronously and asynchronously.
– Support 2xM.2 2280 SATA/PCIE/NVMe SSD+1×2.5” SATA HDD/SSD.
– Support 2.5G&1G Dual RJ45 Lans+M.2 2230 2.4G/5G Dual band AC(AX) WiFi/Bluetooth.
– Full featured Type-C, support 4K@60Hz display, PD3.0 15W fast charge, USB3.2.
– Onboard a powerful copper fan for heat dissipation, keep the computer stable working 7×24 hours.
– Support TPM2.0, PXE, RTC, Wake on LAN, Auto power on.
Product Details
Specification
Ordering information
Product Details
JIRUICC S500+ is a Fan cooling AMD Ryzen 5 Ryzen 9 Powerful Gaming computer with intel Ryzen 5 5500U / Ryzen 7 5800U / Ryzen 7 5825U / Ryzen 9 5900HX with AMD Radeon™ VEGA Graphics
Support 3 Display: 1 x DP1.4, 1 x HDMI2.0, 1 x Type-C for simultaneous
Redefine the new form of computer, Powerful performance, Compact, Space-saving, Fan cooling design, less noise disturbance, Low power consumption and Energy saving, Easy to carry
Widely Application Area: Cybercafe/Office working / Digital signage / Education/Call center /Conference room/Home entertainment /Home theater/Cloud Computing etc…
Specification
| Basic Information: | |||
| CPU | 1. 7nm AMD Ryzen 3 5300U 4 cores 8 threads 2.6GHz up to 3.8GHz TDP 45W AMD Radeon 7 Graphics. 2.7nm AMD Ryzen 5 5625U 6 cores 12 threads 2.3GHz up to 4.3GHz TDP 45W AMD Radeon 7 Graphics. 3. 7nm AMD Ryzen 7 5800U 8 cores 16 threads 1.8GHz up to 4.3GHz 8MB cache TDP 15W AMD Radeon 8 Graphics. 4. 7nm AMD Ryzen 7 5825U 8 cores 16 threads 2.0GHz up to 4.5GHz 8MB cache TDP 15W AMD Radeon 7 Graphics. 5. 7nm AMD Ryzen 9 5900HX 8 cores 16 threads 3.3GHz up to 4.6GHz 16MB cache TDP 45W AMD Radeon 8 Graphics. | ||
| TDP | 45W / 15W | ||
| Motherboard Size | 144 x 141mm customized size | ||
| Chipset | Controller | ||
| BOIS | AMI (American Megatrends Inc.) | ||
| Memory | 2 x SODIMM-DDR4 Slot DDR4 UP TO 3200MHz, LPDDR4 UP TO 4266MHZ | ||
| OS | Windows10/Windows10 pro/Windows11/Ubuntu/Linux | ||
| Audio | Azalia Codec support 2.1 channel output High Definition Audio Controller | ||
| Network | Realtek 8821CE Wireless PCIe GbE Family Controller 10/100Mbps/1000Mbps BaseT LAN | ||
| Video | AMD Radeon 8 Graphics / AMD Radeon Graphics | ||
| Storage: | |||
| M.2 | 2 x M.2 2280 SATA/PCIE/NVMe SSD, up to 2TB | ||
| SATA | 1 x SATA3.0 slot for SATA HDD or SSD | ||
| Wi-Fi: | |||
| Module | 1 x M.2 NGFF 2230(Key E) slot for Wi-Fi module(2.4G/5G Wi-Fi B/G/N/AC or Bluetooth5.0), support WiFi6 module | ||
| Antenna | 2 x inner RF cables without antennas | ||
| Input/output port： | |||
| Switch | 1 x Power On/Off Switch | ||
| Power | 1 x 19V DC In | ||
| Type-C | 1 x Type-C(Support DP/USB 3.2) (4K 60Hz)(PD3.0/120W/20V-5A) Or 1 x Type-C(Support DP/USB 3.2) (4K 60Hz)(PD3.0/60W/20V-3A) | ||
| LED | 1 x LED | ||
| USB | 2 x USB3.2, 4 x USB2.0 | ||
| Display | 1 x DP1.4, 1 x HDMI2.0, 1 x Type-C | ||
| LAN | 2 x RJ45 Giga LAN | ||
| Audio | 1 x Audio(MIC&SPK) | ||
| Power and Working Environment: | |||
| Input | DC100-240V AC/50-60Hz | ||
| Output | 19V/6.32A, 5.5/2.5mm / 19V/4.74A, 5.5/2.5mm | ||
| Operating Temperature | 0/+60 Centigrade | ||
| Storage Temperature | -20/+ 70 Centigrade | ||
| Relative Humidity | 0%~90% (non-condensing) | ||
| Product Dimension & Details: | |||
| Functions | Support TPM2.0, PXE, RTC, Wake on LAN, Auto power on | ||
| Size | 150*145*40mm | ||
| Weight | Net 0.65kg, Gross 1.65kg | ||
| Shell | Aluminum Alloy+ABS | ||
| Cooling Mode | Power Cooling Fan | ||
| Package Content： | |||
| Standard | 1xMini PC, 1xPower Adapter, 1xPower Cord, 1xScrews Bag | ||
| Optional | 1xHDMI cable | ||
Ordering information
| Model | Processor | Graphics | Frequency | Display | Memory | Storage | LAN | USB | Power |
| S500+ | Ryzen 5 5500U | AMD Radeon™ VEGA Graphics | 2.1~4.0 GHz | 1 x DP1.4 1 x HDMI2.0 1 x Type-C | 2 x SO-DIMM DDR4 | 1 x M.2 2280 SATA/NVME SSD/ 1 x SATA3.0 slot for SATA HDD or SSD | 2 | 6 | 19V/4.74A |
| S500+ | Ryzen 7 5800U | AMD Radeon™ VEGA Graphics | 1.9~4.4 GHz | 1 x DP1.4 1 x HDMI2.0 1 x Type-C | 2 x SO-DIMM DDR4 | 1 x M.2 2280 SATA/NVME SSD/ 1 x SATA3.0 slot for SATA HDD or SSD | 2 | 6 | 19V/4.74A |
| S500+ | Ryzen 7 5825U | AMD Radeon™ VEGA Graphics | 2.0~4.5 GHz | 1 x DP1.4 1 x HDMI2.0 1 x Type-C | 2 x SO-DIMM DDR4 | 1 x M.2 2280 SATA/NVME SSD/ 1 x SATA3.0 slot for SATA HDD or SSD | 2 | 6 | 19V/4.74A |
| S500+ | Ryzen 9 5900HX | AMD Radeon™ VEGA Graphics | 3.3~4.6 GHz | 1 x DP1.4 1 x HDMI2.0 1 x Type-C | 2 x SO-DIMM DDR4 | 1 x M.2 2280 SATA/NVME SSD/ 1 x SATA3.0 slot for SATA HDD or SSD | 2 | 6 | 19V/4.74A |
