POE Industrial PC with 4LAN,6COM RS232 RS485,3Display Embedded Box PC
1*HDMI+1*VGA+1*DP+4LAN(Support POE)+GPIO+SIM Card slot+6*RS232+8USB+PS/2
Products Features
– 6 x RS232 COM(COM 1/COM 2 support RS485/RS442).
– 4 x GbE RJ45 Intel i210/i211, support POE.
– Intel 7th Gen Core i5/i7-HQ CPU optional.
– 2 x SODIMM DDR4 memory slot up to 32GB stronger performance.
– Rugged full aluminum alloy black color shell better for heat dissipation.
– Can install M.2 SSD+MSATA SSD+2.5” SATA HDD together.
– Support 3 displays with HDMI, VGA, and DP interfaces, Enjoy 4K Ultra HD videos.
– Support dual PCI, dual PCIE x4 or PCI x4+PCI(optional).
– Support One-key recovery, Watchdog, PXE.
– Installation: Support desktop and wall-mounted
Product Details
Specification
Ordering information
Product Details
POE Embedded BOX PC GT7900 with 3 Display output(HDMI, VGA, and DP)/ Internal SIM Card slot support SIM Card for 3G/4G Module to get network for some products with hard-working
environments that can’t use a Wi-Fi network. it with rich I/O Ports like GPIO/6 x DB9 COM (COM 1/COM 2 support RS485/RS422) / 4 x GbE RJ45 Intel i210/i211, support POE/8USB Ports for connecting with multiple device
for Various industry uses because of the features of Compact, Space-saving, Fanless design, Zero noise disturbance, Low power consumption, and energy-saving
Widely Application Area: Industrial Automation / AI / IOT Internet of Things/CCTV monitoring /Smart Medical/Smart City /Digital Signage/Cloud Computing/Smart
Robot/Smart Transportation/New Retail(Kiosk)/Network Security etc…
Specification
| Basic Information: | |||
| CPU | Onboard 7th Gen 14nm CPU Kaby Lake Intel Core i7-7920HQ 4 cores 8 threads 3.1GHz up to 4.1GHz 8MB cache TDP 45W Intel® HD Graphics 630… | ||
| TDP | 45W | ||
| Chipset | Kaby Lake | ||
| BOIS | AMI BIOS, ACPI supported | ||
| Memory | 2 x SO-DIMM DDR4 Slot Support 4GB/8GB/16GB/32GB DDR4-2400, LPDDR3-2133 | ||
| OS | Windows 7/10, WES 7/10, LINUX | ||
| Audio | ALC892 chip, 6 channel sound, Intel Lynx Point-LP HDA | ||
| Network | 4 x GbE RJ45 Intel i211/i210 Support POE, Support 802.3AF (2 pairs of 13W), 802.3AT (2 pairs of 30W), 802.3BT (4 pairs of 30W) | ||
| Video | Intel® HD Graphics 630 | ||
| Storage: | |||
| MSATA | 1 x M-SATA3.0 slot for MSATA SSD, support 6Gb/s | ||
| M.2 | 1 x M.2 slot for M.2 SSD, only supports NVME 2280 SSD | ||
| SATA | 2 x SATA3.0 slot for SATA HDD or SSD, support 6Gb/s (Only space for 1 x 2.5” SATA HDD/SSD) | ||
| Wi-Fi: | |||
| Module | 1 x Mini-PCIe half/full(with SIM card slot), support 3G/4G module, WIFI, Bluetooth 4 x PCI, 1 x PCIEx8, 2 x PCIEx4(optional) | ||
| Antenna | 2 x inner RF cables and 2 x external antennas | ||
| Input/output port： | |||
| Switch | 1 x Power On/Off Switch | ||
| Power | 1 x 4pin aerial plug power socket, support 9-36V power input | ||
| PS2 | 1 x PS2 (keyboard and mouse combo) | ||
| USB | 6 x USB3.0, 2 x USB2.0 | ||
| Display | 1 x HDMI, 1 x VGA, 1 x DP | ||
| Gpio | 14 x GPIO (7 inputs, 7 outputs) | ||
| LAN | 4 x RJ45 Giga LAN | ||
| Audio | 1 x Audio(MIC&SPK) | ||
| COM | 6 x DB9 COM (COM 1/COM 2 Support RS485/RS422) | ||
| Reset | 1 x Reset Button | ||
| CMOS | 1 x Clear CMOS Button | ||
| Audio | 1 x MIC, 1 x SPK | ||
| AXT/AT | 1 x DIP switch, support ATX/AT boot mode selection | ||
| Power and Working Environment: | |||
| Input | DC100-240V AC/50-60Hz | ||
| Output | 4pin aerial plug power socket, support 9-36V power input | ||
| Operating Temperature | -20°C +50°C | ||
| Storage Temperature | -30°C~70°C | ||
| Relative Humidity | 10%~90% @30°C(non-condensing) | ||
| Product Dimension & Details: | |||
| Functions | One-key recovery, Watchdog, PXE | ||
| Size | 310*203*125mm | ||
| Weight | Net 4.6kg, Gross 5kg | ||
| Shell | Black color aluminum alloy | ||
| Cooling Mode | Fanless | ||
| Package Content： | |||
| Standard | 1xMini PC, 1xPower Adapter, 1xPower Cord, 1xScrews Bag,Wi-Fi antennas, | ||
| Optional | 1xHDMI cable, 1xUser Manual, 1xLong Screws Bag | ||
Ordering information
| Model | Processor | Graphics | Frequency | Display | Memory | Storage | LAN | USB | COM | Power |
| GT7900 | i7-7920HQ | Intel® HD Graphics 630 | 3.1~4.1 GHz | 1 x HDMI 1 x VGA 1 x DP | 2 x SO-DIMM DDR4 | 2 x 2.5 inch stata3.0 1 x M-SATA 3.0 1 x M.2 2280 SATA/NVME SSD | 4 x GbE RJ45 Intel i211/i210 Support POE | 8 | 6 | 4pin aerial plug power socket, support 9-36V power input |
