Industrial Rugged PC 2LAN 2COM GT660
Products Features
Dimension:135mm(L)x127mm(W)x39mm(H)
CPU: Intel 12th Gen N100/Celeron J6412
GPU: Intel UHD Graphics
Ram: 1xDDR4 SODIMM slot, 3200MHz
SSD: Support 1*M.2 2280 NVMe/PCIE3.0x2/SATA+1*MSATA
HDD: Support 2.5inch 7mm SATA HDD/SSD
WiFi: Dual Band AC WiFi5 with Bluethooth4.2(except barebone bundle)
RJ45: 2 x 100/1000M realtek chip
I/O: 2 x USB 3.0, 2 x USB 2.0, 2 x HDMI, 1 x DP, 2 x RJ45 LAN, 2 x DB9 COM, 1 x SPK, 1 x MIC, 1 x switch, 1 x DC IN
OS: Windows 11/OPNsesne/Ubuntu etc
Power: 12V 3-5A
Product Details
Specification
Ordering information
Product Details
Industrial Fanless Computer GT660 with rich I/O Ports like 2*RS232 Dual LAN RJ45 6USB Ports,2HDMI+1DP Triple display for connecting with multiple devices for Various industry uses Like Industrial Automation / AI / IOT Internet of Things/Smart Education /Smart Medical/Smart City /Digital Signage/Cloud Computing/Smart Robot/Smart Transportation/New Retail(Kiosk)/Network Security etc…
Specification
| Basic Information: | |||
| CPU | 1.Onboard Intel Celeron J6412 2.0GHz Max to 2.6GHz Quad Cores Four Threads 2.Onboard Intel Alder Lake Gen12 N100 3.4GHz Quad Core Four Threads | ||
| TDP | Refer to CPU | ||
| Motherboard Size | 120 x 120 mm customized size | ||
| BOIS | American Megatrends Inc | ||
| Chipset | Elkhart Lake | ||
| Memory | 1* SO-DIMM DDR4 Slot Support 4GB/8GB DDR4-2133 | ||
| OS | Windows 10/Linux | ||
| Audio | Intel High Definition Audio Controller | ||
| Network | 2 x Realtek 811H Gigabit Ethernet Controller 10/100Mbps/1000Mbps BaseT LAN | ||
| Video | Intel® UHD Graphics | ||
| Storage: | |||
| MSATA | 1 x M-SATA3.0 slot for MSATA SSD, support 6Gb/s | ||
| SATA | 1 x M.2 slot for NVME 2280 SSD | ||
| M.2 | 1 x SATA3.0 slot for SATA HDD or SSD, , support 6Gb/s | ||
| Wi-Fi: | |||
| Module | 1 x M.2 2230 slot for Wi-Fi & Bluetooth module | ||
| Antenna | 2 x inner RF cables and 2 x external antennas | ||
| Input/output port： | |||
| Switch | 1 x Power On/Off Switch | ||
| Power | 1 x 12V DC In | ||
| USB | 2 x USB3.0 + 2*USB2.0 | ||
| Display | 2 x HDMI 1.4, 1 x DP 1.2 | ||
| LAN | 2 x RJ45 Giga LAN | ||
| Audio | 1 x MIC, 1 x SPK | ||
| COM | 2 x DB9 RS232 COM | ||
| Power and Working Environment: | |||
| Input | 100-240V AC/50-60Hz | ||
| Output | 12V~+19V, recommend 12V/5A | ||
| Operating Temperature | -20°C/+60°C | ||
| Storage Temperature | -30°C/+70°C | ||
| Relative Humidity | 10%~90% @30°C(non-condensing) | ||
| Product Dimension & Details: | |||
| Functions | Watchdog, Auto power on, Wake-On-LAN, PXE | ||
| Size | 135*127*38.7mm | ||
| Weight | Net 0.8kg, Gross 1kg | ||
| Shell | Black color aluminum alloy(any customized color for bulk order) | ||
| Cooling Mode | |||
| Package Content： | |||
| Standard | 1xMini PC, 1xPower Adapter, 1xPower Cord, 1xScrews Bag | ||
| Optional | 1xHDMI cable, 1xUser Manual, 1xVESA Mount (Pay extra) | ||
Ordering information
| Model | Processor | Graphics | Frequency | Display | Memory | Storage | LAN | COM | USB | Power |
| GT660 | J6412 | Intel® UHD Graphics | 2.0GHz up to Max 2.6Ghz | DP x 2HDMI | 1 x SO-DIMM DDR4 | 1 x 2.5 inch/1 x M-SATA/1 x M.2 2280 | 2 | 2 | 4 | 12V/5A |
| GT660 | N100 | Intel® UHD Graphics | Max 3.4Ghz | DP x 2HDMI | 1 x SO-DIMM DDR4 | 1 x 2.5 inch/1 x M-SATA/1 x M.2 2280 | 2 | 2 | 4 | 12V/5A |
