NUC Mini PC i7-13620H i9-13900H S600
Products Features
– Onboard newest 12th Gen Intel Core i5/i7/i9 Processor with powerful computing performance.
– 2xSODIMM DDR4 ram slot up to 64GB, large capacity and high frequency memory improve work
efficiency and give you a smooth experience.
– Support 1*Mini DP 1.4 and 1*HDMI2.0(4K@60Hz),Type-C 8K@60Hz Output.
– Support 1*M.2 2280 NVME/PCIE4.0+1*M.2 2280 NVME/PCIE3.0+1*2.5” SATA HDD/SSD.
– Support 2.5G+1G Dual Network interface, WIFI 6E AX211 Network card Bluetooth 5.2
– Onboard a powerful copper fan for heat dissipation, keep the computer stable working 7×24 hours.
– It can be mounted on the backside of monitor by VESA Bracket.
– Support TPM2.0, PXE, RTC, Wake on LAN, Auto power on etc.
Product Details
Specification
Ordering information
Product Details
Specification
| Basic Information: | ||||
| CPU | 1.Onboard 12th Gen 10nm CPU Alder Lake Intel Core i5-12450H 8 cores 12 threads 2.4GHz up to 4.4GHz 12MB cache TDP 45W 2.Onboard 12th Gen 10nm CPU Alder Lake Intel Core i7-12650H 16 cores 16 threads 2.3GHz up to 4.7GHz 24MB cache TDP 45W 2.Onboard 12th Gen 10nm CPU Alder Lake Intel Core i9-12900H 14 cores 20 threads 2.5GHz up to 5GHz 24MB cache TDP 45W | |||
| TDP | 45W | |||
| Memory | 2 x SO-DIMM DDR4 Slot Support 8GB/16GB/32GB/64GB DDR4-3200Mhz | |||
| OS | Windows 10/11/Linux Ubuntu | |||
| Network | 2.5G+1G Dual Network interface | |||
| Video | Intel®Xe Graphics G7 Ultra HD Core display(Request dual channel DDR4 Memory) | |||
| Wi-Fi: | ||||
| Module | WIFI 6E AX211 Network card Bluetooth 5.2 | |||
| Antenna | 2 x inner RF cables and without external antenna | |||
| Power and Working Environment: | ||||
| Input | DC100-240V AC/50-60Hz | |||
| Output | DC+19V, recommend 19V/4.7A | |||
| Operating Temperature | 0/+70 Centigrade | |||
| Storage Temperature | -20/+85 Centigrade | |||
| Relative Humidity | 10%~85% | |||
| Input/output port： | ||||
| Switch | 1 x Power On/Off Switch | |||
| Power | 1 x 19V Power In | |||
| USB | 2 x USB3.2, 2 x USB2.0 | |||
| Type-C | 1 x Type-C 8K@60Hz Output. | |||
| Display | 1 x Mini DP 1.4, 1x HDMI 2.0, Support 4K@60H,1 x Type-C 8K@60Hz Output. | |||
| LAN | 1 x RJ45 1Giga LAN+1 x RJ45 2.5G | |||
| Audio | 1 x MIC, 1 x SPK | |||
| Storage: | ||||
| M.2 | 1*M.2 2280 NVME/PCIE4.0+1*M.2 2280 NVME/PCIE3.0 | |||
| SATA | 1 x SATA3.0 slot for SATA HDD or SSD, support 6Gb/s | |||
| Product Dimension & Details: | ||||
| Size | 149*145*55MM | |||
| Weight | Net 1kg, Gross 2kg | |||
| Shell | Black color PVP top and Silver aluminum alloy body | |||
| Cooling Mode | Pure Copper Radiator+Super silent large fan | |||
| Functions | TPM2.0, PXE, RTC, Wake on LAN, Auto power on | |||
| Package Content： | ||||
| Standard | 1xMini PC, 1xPower Adapter, 1xPower Cord, 1xScrews Bag | |||
| Optional | 1xHDMI cable, 1xUser Manual | |||
Ordering information
| Model | Processor | Graphics | Frequency | TDP | Display | Memory | Storage | LAN | USB | Power |
| S600 | i5-12450H | Intel UHD Graphics for 12th Gen Intel Processors | 2~4.4 GHz | 45 W | DP/HDMI/Type-C | 2 x SO-DIMM DDR4, up to 64GB | 1*M.2 2280 NVME/PCIE4.0+1*M.2 2280 NVME/PCIE3.0+1 x SATA3.0 | 2 | 4 | 19V/4.7A |
| S600 | i7 12650H | Intel UHD Graphics for 12th Gen Intel Processors | 2.3~4.7GHz | 45 W | DP/HDMI/Type-C | 2 x SO-DIMM DDR4, up to 64GB | 1*M.2 2280 NVME/PCIE4.0+1*M.2 2280 NVME/PCIE3.0+1 x SATA3.0 | 2 | 4 | 19V/4.7A |
| S600 | i9 12900H | Intel Iris Xe Graphics eligible | 2.5~5 GHz | 45 W | DP/HDMI/Type-C | 2 x SO-DIMM DDR4, up to 64GB | 1*M.2 2280 NVME/PCIE4.0+1*M.2 2280 NVME/PCIE3.0+1 x SATA3.0 | 2 | 4 | 19V/4.7A |
